MG Double beams gantry crane is mainly consisting of the skeleton structure, lifting and cross traveling mechanism, long traveling mechanism, cabin and electrical control system. The trolley can move horizontally on a pair of rails on the beam. The beam can be box or trussed type in according to your working environment situation. pressure isless than 125Pa, or more,trussed type gantry crane is always using in outdoor)Cabin used for operating, with seats inside. Floor adopts insulation pads and toughened glass for windows; extinguisher and fan are equipped. Other accessory equipment like aircondition, buzzer,interphone and etc. can be configured according to our client’s request!.The length of cantilevers can be designed to meet the working demands.

Main Features of MG model gantry Crane:

1). Light structure,easy installation and maintenance;
2). Widely used in different places for hoisting such as factories,warehouses and material yards;
3). Reasonable structure,strong bearing capacity ;
4). Low noise, soft starting and stopping ;
5). Safe and reliable operation ;
6). Low cost maintenance, long working life;
7). Strong box type,welding by machine hand.;
8). Wheels,wirerope drum,gears, couplings are processed by CNC manchine center, TOP quality control;
9). Heavy duty slipring motor,Or Sq.cage motor with VVVF, IP54 or IP44,insulation class F or H,soft starting and smooth running
10). Siemens main electric parts are used for durable and safe operation.
11). Prohibited to use in the environment with inflammable,explosive and corrosive media.
